MFT-800
Packaing Leakage tester MFT-800
It is suitable for sealing integrity testing of pharmaceutical packaging to prevent moisture, oxygen, and microorganisms from contaminating products. Medicines: bottled, bagged, boxed, ampoules, vials, cartridges, prefilled needles (PFS), (BFS), (FFS), etc.
Product Features
Regulatory Compliance
Comply with USP , ASTM F2338 standards and FDA standards.
Batch Testing
Semi-automatic detection, suitable for small batch and multi-variety testing.
Accurate Testing
Non-destructive non-destructive testing, high accuracy, repeatability, sensitivity.
Pressure Detection
The instrument is used for vacuum pressure ,pressure decay difference detection.
Leak Conversion
The leak rate can be automatically converted into defect aperture μm.
Data Storage
Database storage of test results for easy quality management.
Touch Interface
Touch-type man-machine interface, simple and quick operation: after setting/selecting the test program, only need to manually put in/take out the test sample.
Application Area
Pharmaceutical
industry
Medical device
industry
Food and beverage
industry
Technical Parameter
| Differential pressure sensor | ±2kpa, error≤0.5%F.S. |
| Differential pressure resolution | 0.1pa |
| Test pressure sensor | Error≤±1%F.S. |
| Test pressure range | -0.1～0.2Mpa /-0.1～0.7MPa/-0.1～1.0Mpa（operational） |
| Minimum detectable aperture | 2μm ( for IV bag minimum 5μm) |
| Display method | 10-inch touch color touch screen |
| Voltage | AC100V-240V, 50/60Hz, power ≤200W |
| Audit trail | >=5 years of storage Multiple event logs, which can be queried according to time |
| Authority management | Login with username and password, level 4 authority, meet FDA 21CFR PART 11 requirements |
| Print function | Built in printer |
| History record | >=300000 storage |
| Data backup | Support U disk to export data |
| Interface | Ethernet USB RS485(operational) |
