GT-1000
Wireless Glove Integrity Tester WGT- 1000
Product Features
Unit Master
Supporting powerful upper computer management software, which can manage multiple detection units at the same time
Customizable Programs
There are multiple program settings to meet the testing requirements of gloves of different specifications and materials
Pressure Monitor
Automatically monitor the pressure in the inflatable sealing ring and the glove during the test
Smart Select
Color touch screen, user-friendly interface design, and can automatically select and match the testing program that best suits the current glove according to different test parameters, and display the date and time.
History Link
Historical records can be transmitted, stored, and inquired
Regular Verify
Comply with FDA/GMP and other regulations and computer system verification requirements
Clean Guard
Meet the IP65 protection level, which is convenient for disinfection and cleaning of equipment
Pressure Range
The pressure detection range can reach 3000Pa, covering all glove detection pressures
Air Flow
The instrument uses a small amount of frequent air intake, and the air intake speed in the glove is uniform to avoid deformation of the glove
Quick Connect
Easy to move, easy to carry, fast connection
Custom Pallet
According to customer needs, we can customize pallets of different sizes to achieve multiple pallet operations on one machine
Compliance Certified
The software complies with 21CFR part11 electronic records and electronic signature certification requirements
Application Area
Pharmaceutical
industry
Medical device
industry
Food and beverage industry
Environmental protection industry
Technical Parameter
| Power supply | DC 12V 20W |
| Built-in battery | 12V lithium battery |
| Test accuracy | Minimum aperture 300μm |
| Test duration | 3-8mins |
| Pressure range | 500-3000Pa |
| Pressure resolution | 0.1Pa |
| Noise | ≤50dB(A) |
| Sealing pressure | ≤ 200 KPa |
| History record | 12000 set |
| Glove recognition method | RFID/manual input |
| Weight | 4.6KG/unit |
| Online glove tray | Can free supply 1 size, if need more customization |
| Pump | buildin pump |
| Dimension | 130*285*180mm |
