Filter Integrity Tester V8.0
Product
Features
Filter Integrity
Can test methods regarding the integrity of the filter;
Efficient Testing
Optimized test operation and shortened test time;
Bilingual Interface
Chinese and English bilingual interface can switch freely;
Ultrafiltration Testing
To implement the integrity test of an ultrafiltration system;
Audit Trail
The instrument comes with an audit trail;
Self-Test Function
Automatic self-test function, self-test of multiple performance functions of the instrument itself, after turning on the instrument has instrument self-test function, report faults in time;
Custom Permissions
Allows for both default and customized authority settings, providing the flexibility to meet the specific needs of on-site production and laboratory management.
Enhanced Accuracy
To meet offline /online testing, using pressure sensors with higher accuracy and lower deviation bands to improve the test accuracy of the instrument;
User Access
Supports up to 1000 user accounts with four levels of user management, offering flexible configurations for different user permissions.
Record Export
Test records and audit trails of the instrument both can be queried and exported；
Standard Interfaces
Rich data interface, the instrument not only includes standard digital and analog interfaces (RS232 / USB);
CE Certified
The instrument got CE certificate.
Optimized Linux
Adopt optimized Linux system;
Flexible Pressure
Multiple pressure units can be switched flexibly
High Capacity
Can test most up to 12-core 20-inch filter cartridges, which greatly improves the user's work efficiency;
User Security
Scientific user management, password login, user classification, electronic signature, etc;
Touch Interface
10-inch true-color touch screen design, friendly human-machine interface, simple, fast and reliable operation;
Custom Connectivity
Can expand data communication and network interface requirements according to customer requirements, and support wireless communication functions;
Thermal Printing
The built-in thermal printer avoids the risk of particle and ink contamination, and can keep the handwriting clear;
Pre-Stored Programs
Can establish 1000 sets of pre-stored programs, which meet multiple filter types and different test conditions in the field;
Custom Solutions
Our independent R&D team designs tailored solutions based on customer needs, backed by years of field experience and professional services to ensure seamless instrument use and provide technical support for filter system design.
Enhanced Control
Increased the display curve of diffusion flow-pressure, realized the display and printing function of three curves, optimized the air intake control unit, and greatly increased the air intake speed and stability;
Application Area
Pharmaceutical
industry
Medical device
industry
Food and beverage industry
Environmental protection industry
Technical Parameter
| Power | 100–240 VAC, 50HZ, 120W |
| Operation Pressure | 100-10000 mbar (150psi) |
| Condition | Ambient：+5℃ ~ +40℃；Relative Humidity：10-80% |
| Dimension（mm） | 292*480*115（height1）*190（height2） |
| Function | Basic bubble point；Manul bubble point; Extensive bubble point；Pressure holding test；Diffusion flow test；water instrusion test；Ultrafitration Membrane Test； |
| Test Accuracy | Upstream Volume Test：± 4%；Bubble Point Test：± 50mbar ； Diffusion Flow Test：± 4% ；Water Immersion：± 0.01ml |
| Test Scope | BP：100-8000mbar DF：1-900ml/min WI：0.01-100ml/min |
| Applied Range | Symmetric and asymmetric membrane test, needle filters, capsule filters, flat filters, cartridge filters (within 12 cores and 20 inches), ultrafiltration membrane packages, ultrafiltration columns, various irregular filters |
| Audit Trial | Audit trail records can exportable and ireeversible |
| Authority Management | User Name and Password to Login ,4 Authority Grades; |
| Reservation Solution(programs) | 1000sets |
| Audit trail record storage | ≥5 years storage |
| Anti-backflow(liquid) device | Customization |
| User quantity | 1000sets |
| Operating System | Linux system |
| Dust and splash level | IP54 |
| Print Function | Built-in printer，can control on PC；choose subject |
| Historical Record | 300000 sets records storage |
| Records Copy | Support USB disk to export （include test curve）； |
| Display Screen | High definition 10 inch ,color touch screen; |
| Work Mode | Online/Offline； |
| Applicable Environment | Above D level |
| Weight | 10.7KG |
