Filter Integrity Tester V4.0
Integtest ® Serials Integrity Tester are designed for testing integrity of filters and filter systems . The State Pharmacopoeia and GMP specification requirements. The V4.0 Integrity Tester is compact, handy to use, and fully automated integrity test instrument, which performs bubble point, diffusion flow, enhanced bubble point, and water-based test for hydrophobic filters.
Product
Features
Real-Time Display
Display of test data and curves in real time, monitoring the whole process of testing.
Water Testing
Water Based test (WH) for Hydrophobic Filter: using purified water as test liquid instead of IPA and Ethanol, thus it can avoid trace quantity of ethanol or IPA contamination when testing filters；
Auto Printing
Provides automatic printing set function, the user can operate more simple and convenient；
History Storage
The instrument can store 500 history record and curve.
Application Area
Pharmaceutical
industry
Medical device
industry
Food and beverage industry
Environmental protection industry
Technical Parameter
| Power Supply | 100-240V AC, 50/60Hz；120W |
| Operation Pressure | 100-8000mbar (115psi) |
| Unit | mbar |
| Operation Condition | Ambient Temperature：+5℃ ~ +40℃；Relative Humidity：10-80% |
| Dimension（mm） | 400（Depth）*240（Width）*270（Height1）*220(Height2) |
| Test Function | Manual Bubble point Test；Basic Bubble Point Test；Extensive Bubble Point Test；Diffusion Flow Test；Water Immersion Test； |
| Test Accuracy | Upstream Volume：± 4%；Bubble Point：≤± 50mbar ；Diffusion Flow Test：≤± 4% ；Water Immersion Test：≤± 0.05ml |
| Test Scope | Bubble Point ：590-6900mbar Diffusion Flow Speed：1-180ml/min WI：0.01-30ml/min |
| Applied Range | Symmetric and asymmetric membrane test, needle filter, filter bag, flat filter, filter cartridge (3 core within 20 inches)； |
| Print Function | Built-in printer |
| Historical Records | 500 sets； |
| Display Screen | 5.7″TFT，Single color； |
| Serials port | RS232； |
| Language | Chinese or English； |
| Work Mode | Online/Offline； |
| Applicable Environment | Above D level |
| Weight | 6.5KG |
