TA-2.0
Total Organic Carbon Analyzer(TOC) TA-2.0
Product Features
Pump-Free Design
The instrument adopts no pump pipe design, and there is no need to configure the pressure reducing valve device for the online testing;
Large Storage
The ultra-large capacity of storage space can be used as the real-time query for raw data;
Custom Solutions
The independent research and development team can carry out the design of specific solutions according to the needs of customer
High-Performance
The instrument adopts the latest high-performance CPU processor, to expand the instrument function and improve the processing speed and accuracy
Streamlined Design
Due to no pump pipe design, there is no need of online accessory (pressure reducing valve), to reduce customers' material use, simplify the installation procedure and make flow rate more stable;
Industry Monitoring
On line monitoring and laboratory testing of pharmaceutical water (purified water, injection water), and cleaning validation, electronic industry, food industry, etc.
Application Area
Pharmaceutical
industry
Medical device
industry
Food and beverage industry
Environmental protection industry
Technical Parameter
| Power Supply | 100-260VAC 50HZ,120W |
| Conductivity Detection Range | 0.055µs/cm-8.000µs/cm |
| Measure Range | 0.001mg/L ～ 1mg/L（1 ～ 1000ppb） |
| Accuracy | ±3% |
| RSD | Repeatability ≤ 3% |
| Resolution | 0.001mg/L |
| Response Time | 5mins |
| Measuring Limit | 0.001 mg/L |
| Sample Temperature | 1-99℃ |
| Applied Range | Online/Offline/ Cleaning Validation |
| Audit trail,Records | ≥ 3years storage |
| Authority Management | User name and password login |
| Print Function | External Printer |
| Data Copy | USB disk to export the data |
| Display Screen | Color Touch Screen |
| Expansion Por | Ethernet Port 232 Serial Port Power Output Port 4-20MA signal output |
| Weight | 8.5KG |
| Dimension(mm) | 400*240*270 |
| Audit trail | customization |
