NBC Serials
Intelligent Liquid Particle Counter NBC series model
Product Features
Universal Application
Independent of geographical location and altitude, the system meets the requirements for high-viscosity products and diverse environments.
Precise Sampling Control
High-pressure injection pump system allows for adjustable sampling volume, ensuring accurate results for various sample types.
Pharmacopoeia Compliance
Meets "Chinese Pharmacopoeia" and international standards for particle testing.
Flexible Sampling
According to the demand of sample injection volume, different high pressure injection systems can be replaced;
Small-Volume Testing
Special program for small injections with automatic particle size and quantity conversion.
3Q Certification
Can provide stand-alone version of 3Q certification documents and information;
Touchscreen Interface
Color touch screen operation: Chinese input, easy and quick operation, powerful function. Multi-channel test data can be displayed at the same time;
Data Storage
There is also a data storage function, which can store a large amount of test data for easy query;
Analysis Software
It can be connected to a computer and has the function of automatic data transmission; it can be connected to the laboratory operating platform for management, and dedicated data analysis software for data storage and statistics
Pharma Particle Analyzer
Meet the 2020 edition of the Chinese Pharmacopoeia, which can directly detect the size and quantity of insoluble particles in injection, sterile powder and pharmaceutical packaging materials.
Laser Accuracy
Adopt high-performance imported laser light source and compensation circuit to ensure the test accuracy of various colorless and colored samples. It can directly detect non-electrolyte inspection products
Solution Detection
The sampling slit and pipeline adopt imported 316L and imported PTFE materials, which can directly detect special solutions such as organic solvents and oil bases;
Customizable Tests
There is a pharmacopoeia standard large infusion test, and the number of tests can be set arbitrarily;
Improved Accuracy
Adopting propeller glass stirrer, the uniform speed can be adjusted, and the stirring speed can be controlled at any time to ensure the uniformity of the particles in the container. Improve data accuracy
Automatic Storage
Equipped with sample name input and automatic storage, convenient and quick operation
Flexible Printing
Automatic data processing and multiple printing modes to meet different printing needs;
Audit Trail
The model with "S" is the audit trail version (including software, without computer);
Application Area
Pharmaceutical
industry
Medical device
industry
Food and beverage industry
Environmental protection industry
Technical Parameter
| Model | NBC-26, NBC-26S, NBC-28, JWG-28S, NBC-36, NBC-36S |
| Aisle | ≥5μm, ≥8μm, ≥10μm, ≥12μm, ≥25μm, ≥100μm (channels can be set arbitrarily according to user needs) |
| Test Range | 1～500μm |
| Pharmacopoeia Channel | ≥10μm、≥25μm、 |
| Sampling volume | 0.2-999.9ml |
| Sampling volume accuracy | <±0.5% |
| Counting range | 0-9999999 tablets |
| Detection of particle concentration | 0-10000 capsules |
| Relative standard deviation | RSD≤ 2% (standard particles≥1000 particles/ml) |
| Sampling time | 5ml (<8 seconds) 100ml (<3 minutes) set sampling time according to requirements |
| Channel resolution | ≥ 95% (≥10μm channel) |
| Stirring speed | 0～2000 rpm, uniform speed adjustable |
| Operating temperature | 0～40℃ |
| Power supply | AC220V±10%；50Hz；≤90W |
| Size | 390*350*470（mm） |
